Acromag’s AcroPack modules improve on the mini PCIe form factor by adding a down-facing connector that securely routes I/O signals through the host carrier card without any extra cabling.  Carrier Cards are available in PCIe, VPX, XMC and other formats.

The AcroPack I/O modules are very small and at 30 x 70mm per module, up to four AcroPacks can plug into a serial card offering any I/O combination.  More than 25 AcroPack modules are now offered for a wide analogue I/O, Digital I/O, Communication and FPGA Computing functions – other functions are coming soon!





Request a quote

To simplify the integration of AcroPack I/O Interface Boards into your host system they maintain the same functionality and memory map of existing Industry Pack (IP) modules.

Acromag provides software support packages for embedded applications running on Linux®, Windows®, or VxWorks® operating systems. The libraries provide generic routines to handle reads, writes, interrupts, and other functions. Demonstration programs enable the developer to quickly exercise the I/O modules before attaching the routines to the application program. This diagnostic tool can save hours of troubleshooting and debugging.

These next generation mezzanine modules are RoHS compliant and ideal for the following industries: military, aerospace, defence, industry, scientific, automation, and development labs.

Reconfigurable FPGA Analogue I/OCounter-TimersDigital I/O
IO Interface
Designed for COT Applications.

Reconfigurable Xilinx FPGA AcroPack Modules allow for custom user defined digital I/O designs in VPX or PCIe based systems
These mezzanine boards perform high-speed and high-resolution A/D and D/A conversion.

The AcroPack® product line updates Acromag's popular Industry Pack I/O modules with a PCIe interface format.
These modules perform event counting, timing and frequency measurement functions.

The AcroPack® product line updates Acromag's popular Industry Pack I/O modules with a PCIe interface format.
These modules interface TTL, on/off, hi/lo logic levels to an embedded computer system.

The AcroPack® product line updates Acromag's popular Industry Pack I/O modules with a PCIe interface format.
Ethernet CommunicationSerial CommunicationMIL-STD-1553 Communication for AcroPack I/OSoftware Support
MIL-STD-1553 Communication
These modules provide a dual redundant
MIL-STD-1553 channel with four open/ground avionics level (+35V) discrete I/O signals in addition to IRIG-B input and Trigger I/O. Hard wired RT address signal input pins are also available at the connector.
Combining different AcroPack module types on one XMC, VPX, or PCIe carrier allows for a simplified modular approach to system assembly.

These modules provide a single port Ethernet which is capable of speeds of 10, 100 or 1000 Mbps data rates.
These modules provide an asynchronous serial communication interface for your system.

The AcroPack® product line updates Acromag's popular Industry Pack I/O modules with a PCIe interface format.
The Acromag AP570 Series is a MIL-STD-1553 Communication Module on a ruggedised Mini PCIe Form Factor. Ideally for avionics databus applications due to its high performance design in a tiny footprint.For faster and easier development, Acromag provides a variety of function libraries for Windows, Linux, VxWorks, and other operating systems.
Carrier Cards for AcroPack I/O ModulesAcroPack Accessories
Carrier Card for AcroPackAccessories
CompactPCI® Serial, XMC, PCI Express or VPX bus carrier cards for AcroPack® modules. Acromag provides a broad selection of hardware accessories to simplify the use of their I/O boards.

This collection of panels, cables, and adapters facilitate field wiring and cable connections between boards within the card cage.
