MIL-STD-1553 XMC Interface Card

The Alta Data MIL-STD-1553 XMC Interface Card combines cutting-edge 32-bit FPGA Protocol Engine Technology with AltaAPI software for superior performance.

It’s ideal for Single Board Computers (SBCs) and carriers for VPX, VME, and cPCI (cPCI/cPCIe/PXI) systems, available in both commercial and rugged configurations.

This card uniquely passes SAE AS4111/4112 protocol tests and features a PCI Express 2.1 high-speed backplane for rapid data transfer.

Read on below to find out more.

Complete the form below to request a quote

Or call us on +61 7 3868-4255

  • This field is for validation purposes and should be left unchanged.

Here’s how to receive a quote for this product

  1. Complete the quote form and submit
  2. A friendly expert will contact you shortly after to discuss your personal needs
  3. We will provide you a simple but comprehensive quote on what it will take to build your Custom Design

It only takes a minute to complete the first step. Start now!

The Alta Data XMC-1553 is a powerful MIL-STD-1553 XMC Interface Card.  Designed to offer the highest 1553 channel count in the industry, with an advanced PCI Express 2.1 backplane.

Key Features MIL-STD-1553 XMC Interface Card:

  • High Channel Count: Provides 1-10 independent, dual redundant (A/B) MIL-STD-1553 channels, supporting 1553A, 1553B, and WMUX PP194 protocols.
  • Versatile Compatibility: Ideal for PCI Express, VPX, VME, Single Board Computers (SBC), CompactPCI (or Express), and PXI systems.
  • Advanced 1553 Software: Comes with Alta’s AltaAPI™ software development kit, compatible with a wide range of operating systems.
  • Reduced Footprint: Upgraded PCI Express 2.1 and internal memory design reduce I/O cycles, power consumption, and weight, freeing up valuable slots in your systems.
  • Protocol Engine: Features Alta’s AltaCore-1553 protocol engine with unique signal capture and signal generator capabilities, enhancing embedded, test, and simulation applications.
  • Remote Terminal and Bus Controller: Supports full TX loop-back verification for bus controller (BC) and remote terminal (RT) functions.
  • Bus Analyzer: Provides advanced monitoring capabilities to analyse bus performance.
  • Robust Design Options: Available in commercial, extended temperature, and conduction-cooled versions.
  • High-Speed Memory: Equipped with one MByte high-speed static RAM per channel.

Operating Modes:

  • Dual Function Models: Operate as Bus Controller (BC)/Monitor (MON) or Multiple Remote Terminals (MRT, 1-32)/Monitor (MON).
  • Full Function Models: Combine BC/Monitor and MRT(1-32)/Monitor modes.

The XMC-1553 card is engineered for reliability and performance, making it a perfect choice for rigorous MIL-STD-1553 test applications and demanding environments.

For more information on the Alta Data XMC-1553 Interface Card and how it can enhance your systems in Australia and New Zealand, please contact Metromatics.  Outside this area, please contact Alta Data directly.
