The WOLF VPX3U-ORIN-CX7-FGX2-SBC (WOLF-14TO) is a 3U VPX Single Board Computer that brings AI Computers for autonomous machines to the edge. Meeting the needs of demanding C5ISR applications. It provides a secure compute node with advanced AI and HPC processing capabilities, high data transfer rates and the cyber security features required to ensure data is protected.
Firstly, the NVIDIA Orin’s embedded Ampere GPU provides CUDA cores and Tensor Cores for data processing, deep learning inference, machine vision, audio processing and video encoding/decoding. The 2048 CUDA cores provides 5.3 TFLOPS for processing. Whilst the 64 Gen3 Tensor cores provides the underlying architecture of deep learning inference computing.
Secondly, it features NVIDIA ConnetX-7 SmartNIC. This provides a secure high speed network data transfer and a configurable PCIe Gen5 Switch. Meeting the needs for C5ISR tasks.
WOLF’s advanced cooling technology moves heat using a low weight, high efficiency path from the hot chip’s ide to the wedgelocks.
Key Features of the 3U VPX Single Board Computer VPX3U-ORIN-CX7-FGX2-SBC are:
- NVIDIA Embedded Ampere GPU with 2048 CUDA Cores (5.3 TFLOPS) & 64 Gen3 Tensor Cores (275 TOPS Int8)*
- Embedded 12-core NVIDIA Cortex ARM64 CPU 2.2GHz
- 64GB LPD DR5 256-bit memory with up to 205 GB/s
- ConnectX-7 up to 100GbE Ethernet, PCIe Gen
- SDI input/output, DP MST output, Analog output
- Module power: configurable from 80W-120W
The rugged SBC performs in rugged environments. Operating in temperatures from -40° to +85°C, exposed to 10G peak vibrations and survive shock of 40G
