Ultra-Lightweight | Rugged Server | High-Performance Storage & Processing for SWaP-C Applications
The Galleon G1 microServer delivers full-featured server capabilities in an ultra-compact, rugged enclosure. Designed for Size, Weight, Power, and Cost (SWaP-C) constrained environments, it is ideal for airborne, ground, and mobile mission platforms where space is limited and performance is critical. Metromatics proudly provides local sales, service, and support for the G1 microServer in Australia.
Applications
The G1 microServer is perfect for:
- Mission Data Servers
- Application Servers
- Network Attached Storage (NAS)
- Ethernet Data Recorders
- Data Loader Systems
Key Benefits
- Ultra-Lightweight Design: Less than 2.6 lb (1.2 kg)
- SWaP-C Optimised: Small, low-power server with powerful processing
- High-Performance Storage: Up to 40TB removable SSD
- High Bandwidth Networking: Quad GbE + optional 10GbE
- Secure Data Handling: NIAP-approved dual-layer encryption
- Docking Support: Easy data transfer between deployed units and ground stations
Core Features
- Intel® C2758 Octal-Core 2.4GHz CPU
- 8GB ECC DDR3 SDRAM
- Quad 1000BASE-T Gigabit Ethernet ports
- Optional 10GBASE-T port for high-speed data recording
- Removable SSDs: Up to 40TB MLC or 20TB SLC
- Software and hardware full disk encryption options (AES-256, FIPS 140-2)
- Compatible with Debian, RedHat Enterprise Linux, Windows 10, and Windows Server
Rear Panel Interfaces
- 4x 1000BASE-T Gigabit Ethernet
- 1x 10GBASE-T (optional)
- 2x USB 2.0
- 2x RS-232
- 2x VGA
- 1x DC Power Input
Storage & Security Options
- Removable SSD Options:
- Up to 40TB Industrial-grade MLC
- Up to 20TB Military-grade SLC
- Up to 256GB SLC Flash for OS
- RAID 0/1 and JBOD support
- FIPS 140-2 certified hardware encryption (optional)
- AES-256 software and hardware encryption
- Supports Galleon’s high-speed data recorder software (up to 500MB/s)
I/O Expansion
- MiniPCI Express expansion slot for additional functionality
Environmental Specifications
- Operating Temp:
- 0°C to +50°C (Standard)
- -40°C to +75°C (Extended)
- Altitude: -1500 to 60,000 ft
- Humidity: Up to 100%, condensing
- Shock/Vibration: MIL-STD-810
- EMI/RFI: MIL-STD-461
- Power Supply: 16–50V DC (MIL-STD-704 compliant)
Why Choose Metromatics?
As Galleon’s authorised distributor in Australia, Metromatics offers:
- Expert local support and technical consultation
- Onshore servicing and integration advice
- Experience with defence, aerospace, and surveillance platformsContact us today to find out how the G1 microServer can be tailored to your mission-critical application.
Contact us today to learn how the XSR Mission Computer can power your next embedded system.
Galleon Embedded Computers, part of the Spectra Defence Technology family alongside Calculex and Argon FDS, delivers rugged data acquisition, storage, computing, and display solutions for demanding military platforms. Metromatics is the authorised Australian distributor, providing local sales, service, and support to ensure mission success.
