Multi Axis Load Cell Sensors

Multi Axis Load Cells measure multiple forces simultaneously, providing accurate and reliable data on the multiple axes in real time.

They are often used to measure motion, force and torque in applications in the fields of Robotics, Aerospace, Automotive Testing, Medical Device Testing and in Industrial Automation.

The Multi Axis Sensors have a capacity of 4.53 kg (44.48 N) to 11,339 kg (111200 N) and are available in 2-axis, 3-axis, 6-axis load cell or automotive versions.

Metromatics proudly back up the FUTEK product range with local knowledge, service and support to our customers in Australia and New Zealand.

Complete the form below to request a quote

Or call us on +61 7 3868-4255

  • This field is for validation purposes and should be left unchanged.

Here’s how to receive a quote for this product

  1. Complete the quote form and submit
  2. A friendly expert will contact you shortly after to discuss your personal needs
  3. We will provide you a simple but comprehensive quote on what it will take to build your Custom Design

It only takes a minute to complete the first step. Start now!

Multi-Axis Load Cell Sensors Explained

A Multi-Axis Load Cell is a special sensor that can measure different forces and twists (torques) all at the same time and in various directions. Think of it like a super sensor that can feel pushes, pulls, and turns in multiple ways.  Often referred to as Multi Component.

These sensors can measure up to 6 kinds of forces at once. This includes straight pushes/pulls (like Fx, Fy, Fz) and twists (like Torque Mx, My, Mz) in three main directions. After measuring, the sensor changes these forces into an electric signal.

Our partner, FUTEK, makes many types of these sensors. Some can measure forces in 2, 3, or even 6 different ways. They even have special ones for cars!

Where are these sensors used? Lots of places! Robots, spaceships, and cars are just a few examples. Because they can measure so many forces, they help in understanding and controlling how machines work and move.

BiAxial Load Cell

Torque and Thrust Biaxial Sensor

Gear Stick Knob Load Cell

biaxel multi axis load celltorque and thrust multi axis load cellgear stick multi axis load cell

MBA400 – multi axis sensor measuring Fx and Fy loads. Suitable for measuring compressive force including on perpendicular axes.

MBA500 – measure reaction torque moments and tension and compression loads

MAU300 – for the automotive industry with Fx and Fy Loads being tested during shifting.

Custom Multi Axis Force Torque Sensors

Low Profile Thrust and Movement Multi Axis Sensor

Low Profile Thrust and Movement Multi Axis Sensor

QMA Series Custom Multi Axis Sensorslow profile multi axis load cellLow profile thrust multi axis sensor

QMA – Several Custom made models – 3 Axis, 6 Axis, Thru Hole Models and more

MTA500 – multi axis force transducer for measuring Mx, My and Fz loads.

MTA505 – multi axis force sensors measuring Mx, My and Fz large loads up to 11,000 Kgs.

Triaxial Load Cell

Triaxial Load Cell

Triaxial Load CellTriaxial Load Cell

MTA400 – measuring Fx, Fy and Fz loads.

MTA600 – measuring Fx, Fy and Fz loads.

Advantages of FUTEK Axis Load Cell Sensor Range include

  1. Multi Axis Measurement Capabilities: FUTEK’s Multiple Axis Sensors can measure multiple axes at the same time, providing accurate and reliable data on multiple parameters in real-time.
  2. High Precision: Designed with high precision. Thus, ensuring that the measurements taken are correct and consistent.
  3. As well as Customisable Options: FUTEK’s Load Cells can be customised to meet specific application requirements. This includes size, shape and measurement range.
  4. Durable Construction: FUTEK’s products are made from high quality materials. This allows them to with stand harsh environmental conditions.

Applications where FUTEK Multi Axis Sensors are used include:

  1. Robotics: Used in robotic applications to measure and monitor forces, torques and motion.
  2. Aerospace: Monitor and measure vibrations, forces and torques on Aircraft including Wings
  3. Automotive: Monitor and measure vehicle dynamics. Such as braking, steering and acceleration.
  4. Medical: In addition, used to monitor and measure forces and torque in medical devices. Such as prosthetics and surgical tools for key hole surgery.
  5. Industrial Automation: Used to monitor and measure forces, torques and motion in machinery and equipment.

For more information, contact us.

About FUTEK Advanced Sensor Technology

FUTEK Advanced Sensor Technology, Inc. is a leader in the design and manufacture of sensors and test and measurement instruments. Firstly, the Sensor range that FUTEK specialises in includes: load cells, torque sensors, pressure sensors, multi-axis sensors, and related instruments and software

Secondly, founded in 1985. FUTEK provides Aerospace and Defence, Pharmaceutical and Medical, Engineering, Research and Manufacturing markets with in-house customisation, engineering, integration, calibration, product life-cycle planning, warranty, and support services.

In addition, FUTEK’s product quality and in-house support is brilliant. All products manufactured at the company’s Irvine, California USA factory; facility certified to ISO 9001:2015 & ISO 17025 accredited quality management standards.

Finally, Metromatics proudly back up the FUTEK product range with local knowledge, service and support to our customers in Australia and New Zealand.
